Input

• Sensing voltage: 170-300 VAC / 320-600 VAC (selectable via input terminals)
• Supply voltage: 170-300 VAC
• Frequency compatibility: 50/60 Hz (selectable)

Output

• Excitation voltage: 76.5 Vdc - 135 Vdc
• Excitation current: 7 Adc (continuous)

Regulation

• Steady-state voltage regulation: ≤ ±1% RMS (standard engine governing)
• Under-frequency (U/F) protection: 50 Hz or 60 Hz selectable
• Analog auxiliary input: ±3V, ±5V, ±10V DC (selectable via jumper)
• Voltage adjustment: On-board potentiometer (Vad)

Protection

• Under-frequency (U/F) protection
• Sensing fault protection
• Over-excitation protection
• Short-circuit current limitation

Environment

• Operating temperature range: -40°C to +60°C
• Compliance: RoHS compliant

Additional Features

• Designed for synchronous generators with excitation current up to 7A
• Analog input selectable via jumper
• Parallel operation capability
• Compatible with brushless synchronous alternators
