Brushless 5kw Generator AVR R449

Brushless 5kw Generator AVR R449


Generator Universal AVR R499 For AC Brushless Generator AVR 3 Phases is a half-wave phase controlled thyristor

type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to

regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe,

reliable control of the generator.
Positive voltage build up from residual levels is ensured by the use of proficient semiconductors in the power circuitry of the AVR.

Which is linked with the main stator windings and the exciter field windings to offer closed loop control of the output voltage with

load regulations of +/- 1.5%.
