EA05A

Generator Universal Automatic Voltage Regulator AVR EA05A

EA05A
Quantity:
0.00
Contact Now
add to cart
Buy Now

Generator Universal AVR Automatic Voltage Regulator AVR EA05A

EA05A


Sensing Input
Voltage 220 / 380 / 440 VAC, 1 phase2 wire
DIP switch selectable
Frequency 50 / 60 Hz, DIP switch selectable
Power Input
Voltage 100 ~ 300 VAC, 1 phase 2 wire
Output
Voltage Max. 63 VDC @ 220 VAC input
Max. 90 VDC @ 240 VAC input
Current Continuous 5A
Intermittent 7A for 10 sec
Resistance Min. 15 ohm Max. 100 ohm
Voltage Regulation
< ± 0.5% ( with 4% engine governing )
Voltage Build-up
Residual voltage at AVR terminal > 5 VAC
Thermal Drift
0.03% per °C change in AVR ambient

EA05A
EA05A
EA05A
