25KVA AVR Generator Voltage Stabilizer R450M
R450M
Quantity:
0.00
25KVA AVR Generator Voltage Stabilizer R450M
Generator Universal AVR r450m For AC Brushless Generator AVR 3 Phases is a half-wave phase controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator.
Generator Universal AVR r450m For AC Brushless Generator AVR 3 Phases is a half-wave phase controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator.
| Input | Voltage: | 190~264V ac | |
| Frequency: | 50-60 HZ nominal | ||
Output | Voltage: | max 90V dc at 207V ac input | |
| Current: | continuous 4 A dc,Intermittent 6A for 10 secs | ||
| Resistance: | 15 ohms minimum | ||
| REGULATION | ±1% | ||
